★ | WZ-7(F)型 小量程压式称重传感器 | 阅读数:1975 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
关键词:
称重传感器 |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
The single strain beam structure is adopted and can weigh small load accurately. It has overload protector and metal shell for safety and can work in bad condition for long time. It is suitable for electronical scales like belt scales in cement factory and hopper scales etc. 量程范围(Scaling Range [kg]):5,10,15,20,30,50,100,150,200,300 准确度等级(Accuracy Degree):0.1 材质(Material): 合金结构钢 技术指标 (Technical Specification):
红——输入(+);黑/兰——输入(-);绿——输出(+);白——输出(-)。 Red—Input(+);Black/Blue—Input(-);Green—Output(+);White—Output(-) 其他说明(Note): 可按用户要求量程和外形尺寸供货。 We can supply according to scaling range and shape dimension required by users.
|
